Appearance size diagram
Type and technical parameters:
* special products
Type and technical parameters:
| type | Product No. | pipe diameter | Ød | L | T | T1 | H | weight（g） |
| PI0401 | 30102 | Ø4 | 2 | 21 | M8x1.0 | PT1/8" | 12.7 | 17 |
| *PI0401Z | Ø4 | 2 | 21 | M8x1.0 | Z1/8" | 12.7 | 17 | |
| PI0408 | Ø4 | 2 | 21 | M8x1.0 | M8x1.0 | 12.7 | 15 | |
| PI0410 | Ø4 | 2 | 21 | M8x1.0 | M10x1.0 | 12.7 | 15 | |
| PI0601 | Ø4 | 2 | 22.3 | M10x1.0 | PT1/8" | 12.7 | 15 | |
| PI0610 | Ø4 | 2 | 22.3 | M10x1.0 | M10x1.0 | 14 | 21.8 | |
| PI0101 | 2.5 | 21 | PS1/8" | PT1/8" | 12.7 | 15 |
