Type and technical parameters:

type	Product No.	T/T1	Export caliber	Export number	A	B	weight（g）
DB04104	30203	Ø4 Ø4	2-Ø4	4	48	34-36	59
DB04204		Ø6 Ø4	2-Ø4
DB04304		Ø6 Ø6	2-Ø4
DB04306		Ø6 Ø6	2-Ø6
DB05104		Ø4 Ø4	3-Ø4	5	64	49-52	76
DB05204		Ø6 Ø4	3-Ø4
DB05304		Ø6 Ø6	3-Ø4
DB05306		Ø6 Ø6	3-Ø6
DB06104		Ø4 Ø4	4-Ø4	6	80	65-68	96
DB06204		Ø6 Ø4	4-Ø4
DB06304		Ø6 Ø6	4-Ø4
DB06306		Ø6 Ø6	4-Ø6
DB07104		Ø4 Ø4	5-Ø4	7	96	79-84	113
DB07204		Ø6 Ø4	5-Ø4
DB07304		Ø6 Ø6	5-Ø4
DB07306		Ø6 Ø6	5-Ø6
DB08104		Ø4 Ø4	6-Ø4	8	112	95-100	135
DB08204		Ø6 Ø4	6-Ø4
DB08304		Ø6 Ø6	6-Ø4
DB08306		Ø6 Ø6	6-Ø6
DB09104		Ø4 Ø4	7-Ø4	9	128	109-116	145
DB09204		Ø6 Ø4	7-Ø4
DB09304		Ø6 Ø6	7-Ø4
DB09306		Ø6 Ø6	7-Ø6
DB10104		Ø4 Ø4	8-Ø4	10	144	123-132	164
DB10204		Ø6 Ø4	8-Ø4
DB10304		Ø6 Ø6	8-Ø4
DB10306		Ø6 Ø6	8-Ø6
DB12104		Ø4 Ø4	10-Ø4	12	176	153-164	201
DB12204		Ø6 Ø4	10-Ø4
DB12304		Ø6 Ø6	10-Ø4
DB12306		Ø6 Ø6	10-Ø6

Remarks: Ø4 interface tooth pattern is M8x1.0:; Ø6 interface tooth pattern is M10x1.0; other special products can be customized.

Note: the 4 interface is M8x1.0:; the 6 interface is M10x1.0; other special products can be customized.
