Name specification
Performance and characteristics:
1. won the EU CE certification.
2. the pressure adjustment valve is attached with the function of adjusting the pressure in the tube and is attached.
The pressure gauge can be used to indicate the pressure in the tube.
3. the constant pressure function between the release pressure can protect the pump and the pipeline to reduce the damage.
4. motor can be operated for a long time.
5. is equipped with a power indicator, which can be displayed to the oil - like bear (YAC-B1).
6. has a "FEED" key, which can be forced to lubricate (YAC-B1).
Scope of application
The YAC type machine is suitable for the centralized lubrication system of machine tools, plastics, textile, light industry, printing and conveyor.
1. won the EU CE certification.
2. the pressure adjustment valve is attached with the function of adjusting the pressure in the tube and is attached.
The pressure gauge can be used to indicate the pressure in the tube.
3. the constant pressure function between the release pressure can protect the pump and the pipeline to reduce the damage.
4. motor can be operated for a long time.
5. is equipped with a power indicator, which can be displayed to the oil - like bear (YAC-B1).
6. has a "FEED" key, which can be forced to lubricate (YAC-B1).
Scope of application
The YAC type machine is suitable for the centralized lubrication system of machine tools, plastics, textile, light industry, printing and conveyor.
Appearance size diagram
Type and technical parameters:
Type and technical parameters:
|
Product No. | Single phase Voltage (VAC) | Power (W) | Abnormal output connection capacity (A) | Lubrication time | Interval time | Spit out the caliber | Maximum spitting pressure (kgf/cm2) | The amount of spitting (cc/min) | Pressure switch (kgf/cm²) | Liquid level switch | Oil tank capacity (L) | Weight (kg) | |||||
| YAC-H1 | 111102 |
110 220 |
25 40 |
Liquid level switch | The PLC control system must be connected to the | The PLC control system must be connected to the | 4 | 10 |
300 400 |
No | Upper power (oil conduction) | 3L (resin) |
4.2 4.5 4.9 |
|||||
| YAC-B1 | 0.3 | |||||||||||||||||
| YAC-H1P1 | Pressure switch | 2.1↑ off | ||||||||||||||||
| YAC-B1P1 | 3 | |||||||||||||||||
Wiring diagram
Hydraulic schematic diagram
