Performance and characteristics:
1. the three mode of open machine can be set:
(a) lubrication: the lubrication interval is executed first when the machine is opened.
(b) intermittence: the intermission time is executed first.
(c) memory: the time before the start of the machine.
2. lubrication and interval time can be adjusted.
3. controller has two sets of signal connections which can detect liquid level pressure and distributor.
The number of signals when the buzzer is insufficient the alarm is issued (the pressure and the count is the same group.
The signal connection can not be used at the same time) and the abnormal signal can be output to the external control device.
4. lubrication time (second / minute) and interval time (second / minute / time / time) unit can be selected.
5. panel screen and the indicator light can show the actuation and abnormal state of the oil injector.
6. has the "RES" key which can be forced to lubricate.
7. voltage specification AC220/110V 50/60Hz DC24/12V
8. load power is less than 90W
9. protection grade IP54
