Performance and characteristics:
1: the work pressure can be adjusted and displayed through the pressure gauge;
2: an adjustable pressure relay can be used to detect the pressure of the pipeline and output by electric signal.
3: a liquid level switch can be used to output the abnormal signal of the liquid level.
4: the throttle valve is set up to control the flow of oil.
5: a fine filter is set up in the oil outlet and the signal can be sent through a differential transmitter.
6: the return oil port is set back to the oil magnets and filter so as to ensure the cleaning of the oil recovery.
7: oil can be recycled to save oil.
8: it is easy to maintain and all filters can be replaced without opening the lid of the box.
9: the application of oil VG30 to 150cSt.

Scope of application:
The YLS machine is suitable for the resistant system and circulation system. It provides reliable lubrication for large machinery and equipment such as machine tools injection molding machines. According to the different needs of customers various lubricating stations and hydraulic stations can be designed and manufactured.
