Name specification

Performance and characteristics:
1, YBP is a lubricating oil injection machine which uses compressed air as a power source for piston mechanism.
2, pneumatic two parts, solenoid valves, proportions (joint) distributor in the machine, and so on.
3. The PLC system on the main engine controls the solenoid valve to control the oil supply period of the lubricating system.
4. There is a liquid level switch in the machine platform, which can output the abnormal signal of the liquid level, and also have a counter device to prevent the oil from returning to the pipeline.

Scope of application:
The YBP type machine is suitable for high speed and high precision machinery.

Appearance size diagram Type and technical parameters:

Project Type		Product No.	Inlet pipe diameter	Spit out the caliber	Rated oil discharge (cc/cy)	Gas source pressure (kgf/cm²)	Turbocharging ratio	Maximum working frequency (cy/min)	Oil back	Oil tank capacity (L)	Weight (kg)
YBP-K1		111301	Ø 4	4	2.8 (2L)	5 ~ 8	4:1	10	Must be selected with	2L (resin)	1.4
					6 (3L)					3L (resin)	2
