Performance and features:

1. The intermittent and lubrication time of the oil pump is controlled by the PLC system on the mechanical equipment

2. The deceleration motor drives the piston group through the rotation of the crank to actuate the reciprocating motion of oil absorption and discharge in the pump body.

3, using a new type of oil suppression block, clean oil, prevent rollover.

4. The constant pressure function of pressure release valve can ensure the service life.

5, with electromagnetic valve pressure relief to ensure the reliability of pressure relief.

6. It is convenient and quick to replace the canned oil without auxiliary equipment.

7, can be used with YGL-L manual grease gun to add oil to facilitate fast refueling (plus special quick insert public parts)

8, apply grease grease: 000 # ~ 0 #.



Application scope:

YGL-GS machine is suitable for medium and small mechanical equipment, such as construction machinery, textile, printing, machine tools and other machinery.

Wiring diagram
