Name specification

Performance and characteristics:
1. won the EU CE certification.
2. the three mode of open machine can be set:
(a) lubrication: the timing of the lubrication time is first performed when the machine is opened.
(b) intermittence: the interval time is executed first.
(c) memory: the time before the start of the machine.
3. lubrication and interval time can be adjusted.
4. with a liquid level switch, when the oil is insufficient, the buzzer will send out an alarm to output the abnormal signal of the liquid level.
5. there is a depressurized device in the volumetric system.
6. pressure relief valve can protect the pump and pipeline to reduce damage.
7. panel indicator can display the actuation and state of the oil injector.
8. has a "RES" key, which can be forced to lubricate.
9. lubrication time (second / minute) and interval time (second / minute / time ) unit can be selected.
10. can be set as the basis of intermittent cycle counting according to the frequency of mechanical action.
11. motor can be operated for a long time.
12. the pressure switch can be selected freely according to the requirements of the customer (YAE-A2P2).

Scope of application
The YAE type machine is suitable for the centralized lubrication system of machine tools, plastics, textile, light industry, printing and conveyor.
